Nissan Juke Service and Repair Manual : Special Service Tool
Preparation
...
Other materials:
Locking with power door lock switch
Driver’s armrest
Operating the power door lock switch will lock or unlock all the doors. The switch
is located on the driver’s door armrest.
To lock the doors, push the power door lock switch to the lock position 1 with
the driver’s door open, then close the door.
When locking the doo ...
Wiring diagram
Engine control system
For connector terminal arrangements, harness layouts, and alphabets in a
(option abbreviation; if not
described in wiring diagram), refer to GI-12, "Connector Information/Explanation
of Option Abbreviation".
...
Combination switch input circuit
Diagnosis Procedure
1.CHECK INPUT 1 - 5 CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect BCM and combination switch connectors.
3. Check continuity between BCM harness connector and combination switch harness
connector.
Does continuity exist?
YES >> GO TO 2.
NO >> ...
