Nissan Juke Service and Repair Manual : Commercial Service Tools
Periodic maintenance
FUEL SYSTEM
Inspection
Inspect fuel lines, fuel filler cap, and fuel tank for improper attachment,
leakage, cracks, damage, loose connections, chafing or deterioration.
A : Engine
B : Fuel line
...
